Upgrade your system with bold, full-range performance using the Diamond Audio DMDX69 6"x 9" 2-way concentric coaxial speakers, engineered for high-fidelity sound, powerful output, and everyday value. Part of the advanced DMDX Series, these speakers are designed to deliver clean, dynamic audio that far exceeds factory sound systems.

At the heart of the DMDX69 is its concentric coaxial design, aligning the tweeter and woofer on the same axis for superior phase alignment and natural sound reproduction. This results in a wider soundstage, improved imaging, and more accurate detail, allowing vocals and instruments to feel precisely placed within your listening environment.

With 65W RMS / 195W MAX power handling, these 6"x 9" coaxial speakers deliver strong, distortion-free output with impressive headroom. The 88dB sensitivity ensures efficient performance, allowing you to achieve loud, clear sound even with factory head units or moderate amplification.

The extended frequency response (50Hz–20kHz) provides deep, punchy bass, rich midrange detail, and crisp high frequencies, creating a balanced and immersive listening experience across all genres. Whether you're cruising the highway or parked at a meet, your music will sound powerful and refined.

Built with premium materials and Diamond Audio’s proven engineering, the DMDX69 is designed for long-lasting durability and consistent performance. The 3.17-inch mounting depth and vehicle-friendly dimensions make installation straightforward in most cars, trucks, and SUVs.

Key Features:

• Model: DMDX69 – DMDX Series

• 6"x 9" 2-way concentric coaxial speakers

• 65W RMS / 195W MAX power handling

• Concentric design for improved imaging and soundstage

• Wide frequency response: 50Hz–20kHz

• 88dB sensitivity for efficient output

• Ideal for OEM upgrades and aftermarket systems

The Diamond Audio DMDX69 delivers deep bass, clear mids, and crisp highs, making it the perfect upgrade for drivers seeking affordable, high-performance 6"x 9" speakers with true high-fidelity sound and everyday reliability.

Specifications:

• Power Handling - Watts (RMS/Peak): 65W RMS / 195W MAX

• Frequency Response (Hz): 50Hz-20KHz

• Sensitivity (1W/1M): 88dB

• Nominal Impedance (ohms): 4Ω

• Free-Air Resonance (Hz): 68Hz

• Nominal Diameter -inch (mm): 6"x9" (152x228mm)

• Mounting Depth-inch (mm): 3.17" (80.6mm)

• Cut-Out Diameter -inch (mm): 8.68"x5.93" (220.5x150.5mm)

• Overall Diameter -inch (mm): 9.29"x6.4" (236x162.6mm)

• Overall Height -inch (mm): 3.54" (90mm)
