The SounDigital 20000.1 EVOX 1-OHM monoblock amplifier delivers extreme power in a compact footprint, engineered for serious car audio enthusiasts.

Featuring the proprietary RTGP (Thermal Recovery for Power Generation) system, this amplifier achieves exceptional thermal efficiency and stability while maintaining robust performance.

With 20,000 watts RMS @ 1-ohm and scalable output across multiple impedance loads, it handles demanding subwoofer applications with precision. The wide operating voltage range (8V-16V) ensures reliable performance across various vehicle electrical systems.

Built with premium components and cutting-edge thermal management technology, the EVO X Line represents SounDigital's commitment to innovation in high-powered car audio amplification.

Specifications:

• Rms Power @ 12.6V @ 4-ohm: 1 x 8712 Watts

• Rms Power @ 12.6V @ 2-ohm: 1 x 13200 Watts

• Rms Power @ 12.6V @ 1-ohm: 1 x 20000 Watts

• Rms Power @ 14.4V @ 4-ohm: 1 x 9714 Watts

• Rms Power @ 14.4V @ 2-ohm: 1 x 14718 Watts

• Rms Power @ 14.4V @ 1-ohm: 1 X 22300 Watts

• Operating Voltage: 8V – 16V

• Current Draw (Music): 980 A

• Current Draw (Max): 1960 A

• Recommended Fuse (Music): 1000 A

• Total Efficiency: 81%

• Damping Factor: 200

• Frequency Response (-3dB): 5Hz – 500Hz

• SNR: 76dB

• Crossover HPF: 5Hz – 30Hz

• Crossover LPF: 50Hz – 500Hz

• THD + N (10% Rated Power): 0.2%

Measurements:

• 33.9" x 8.8" x 2.8"
