6-Channel High-to-Low Level Line Output Converter with Remote Turn-On

DS18’s MTLOC6 converts up to six factory speaker outputs to six RCA low-level signals. Selectable impedance settings and input modes make it compatible with various factory stereo configurations.

Automatic Turn-On Features
Trigger your amplifier via audio sensing, DC offset, or remote wire for convenience and reliability.

Robust Construction
A durable anodized aluminum housing with thermal and noise protection guarantees long-lasting performance in any environment.

Audio Purity
Delivering less than 0.01% distortion across 10Hz–20kHz, the MTLOC6 preserves your music’s detail and power.

Key Features:

• 6-Channel High-to-Low Conversion

• Selectable Impedance & Input Modes

• Auto Turn-On (Audio / DC / Remote)

• Anodized Aluminum Housing & Noise Protection

• 10Hz–20kHz Frequency Range (<0.01% THD)

Specifications:

• Maximum Speaker Level Input: Up to 40V (400 watts RMS)

• Maximum Preamp Output: Up to 11V

• Nominal Conversion Ratio: 4:1

• Frequency Response: 10Hz - 20kHz

• Total Harmonic Distortion: 0.01%

• Signal To Noise Ratio: >110dB

• Input Impedance: Selectable 20 / 60 / 20k ohms

• Output Impedance: 100 ohms

• Power Draw: 230mA

• Recommended Fuse Rating: 1A

Features:

• Bass Boost: 0 - 12dB

• Auto Turn-On: Yes (Audio Sens / REM / DC)

• Remote Output: Yes

• Level Matching Controls: Yes

• Dash Remote Level Control: Yes

• Led Indicators: Power / Clip

• Housing Material / Color: Aluminum / Black

• Wiring Connector: 14ga Quick Connector

• Ground Isolation: Selectable (200 ohms / Isolated / Grounded)

• Step-Down Method: Transformer

• Input Selector: Selectable (2ch / 6ch)

Measurement:

• Overall Length: 5.7" / 145mm

• Overall Width: 4.5" / 114mm

• Overall Height: 1.1" / 28mm
