• Diseño bidireccional implementado para una calidad de rango completo en cada escucha
• Bordes de goma con conos de papel tratado para un gran volumen y relación sensibilidad-potencia.

• Diámetro nominal: 5X7"/127x177mm
• Impedancia nominal: 4 ohmios
• Manejo de potencia RMS: 50W
• Manejo de potencia MÁXIMA: 150W
• Sensibilidad (1w/1m): 85dB
• Respuesta de frecuencia: 40Hz-20KHz
• Crossover de paso alto recomendado: 70 Hz

• Diámetro de la bobina móvil: 1"/25,5 mm
• Material anterior de la bobina móvil: ASV
• Material de bobinado: EISV
• Material del cono: papel
• Material envolvente: caucho
• Material de la cesta: Acero
• Color/acabado de la cesta: negro mate.
• Material del imán: ferrita de bario
• Peso del imán: 7,8 oz/221 g

• Diámetro nominal: 1"/25,5 mm
• Diámetro de la bobina móvil: 0,5"/13,25 mm
• Material anterior de la bobina móvil: ASV
• Material de bobinado: EISVM
• Material del diafragma: Mylar
• Material del imán: Neodimio
• Peso del imán: 1,8 g

• Diámetro total: 5,57"x7,6"/141,5x193mm
• Profundidad total: 2,63"/66,8 mm
• Recorte del deflector de montaje frontal: 4,9"x7" / 126x180 mm
• Profundidad de montaje: 2,13"/54 mm
• Diámetro del motor: 3,4"/86 mm
• Protrusión del tweeter: 0,5"/12,8 mm
