• Amplificador clase A/B de rango completo
• Fuente de alimentación con modulación de ancho de pulso MOS-FET dual
• Estéreo estable de 2 ohmios / Topología mono de 4 ohmios / Estable de 16 voltios
• PCB epoxi de doble cara con capa de cobre resistente de 3 onzas
• Componentes eléctricos de tolerancia extremadamente alta para mayor confiabilidad
• Disipador de calor personalizado patentado con soporte de PCB integrado para resistencia a las vibraciones
• Entradas RCA Tiffany plateadas de alta gama con potenciómetros metálicos
• Entradas de alimentación y tierra de 4 AWG de gran tamaño, moldeadas en negro
• Tecnología de espejo (canal 1/2 a 3/4) con indicadores de recorte individuales
• Circuito de protección multicapa a prueba de balas
• Graves/Ganancia remotos con indicador de recorte

• Potencia nominal (14,4 V a 1% THD)
• Potencia RMS: 4 ohmios en puente: 220 W x 2 canales
• Potencia RMS - Estéreo de 2 ohmios: 110 W x 4 canales
• Potencia RMS - Estéreo de 4 ohmios: 75 W x 4 canales
• Filtro de paso bajo (12 dB/Oct.): 50 Hz - 5000 Hz (X1, X10)
• Filtro de paso alto (12 dB/Oct.): 50 Hz - 5000 Hz (X1, X10)
• Filtro subsónico (12 dB/Oct.): 10 Hz - 500 Hz
• Respuesta de frecuencia (+/-1dB): 20 Hz - 20 000 Hz
• Separación de canales: 95 dB
• Sensibilidad de entrada (voltios +/- 5%) : 6,0 V - 0,2 V
• Relación señal/ruido: 105 dB.
• Factor de amortiguación (4 ohmios): 200 +
• Modo de funcionamiento: Espejo CH1/2 > CH3/4
• LED indicador de recorte: CH1/2 y CH3/4
• Eficiencia energética (4 ohmios): 65%
• Clasificación del fusible (14,4 V): 60 A.
• Conexión de entrada de energía: calibre 4
• Voltaje de funcionamiento: 8,50 V - 16,0 V
• Conexión de salida del altavoz: calibre 8
• Dimensiones (pulgadas): 7,48 ancho x 2,24 alto x 12,60 largo
• Dimensiones (milímetros): 190 ancho x 57 alto x 320 largo
