El ZR800.4D está diseñado para ofrecer 2 x 600 vatios RMS a 4 ohmios en puente, 4 x 320 vatios RMS a 2 ohmios y 4 x 200 vatios RMS a 4 ohmios, lo que le brinda la potencia perfecta para su bajo.

Características clave

• Amplificador digital de rango completo clase D
• Potencia máxima: 3600 vatios pico
• Potencia RMS: 2 x 600 vatios RMS a 4 ohmios en puente, 4 x 320 vatios RMS a 2 ohmios, 4 x 200 vatios RMS a 4 ohmios
• Respuesta de frecuencia: 20 Hz – 20 KHz
• Relación señal-ruido: >90dB
• Eficiencia a 4 ohmios: 88%
• Distorsión armónica total: 1%
• Rango de entrada: 0,2 v - 6 v
• X-Over seleccionable: COMPLETO/LPF/HPF
• Indicador LED: Recorte, Encendido, Proteger
• Terminal de alimentación y tierra: 4 Ga
• Impedancia mínima: 2 ohmios (estéreo) / 4 ohmios (puente)

Fuerza:

• Vatios totales (pico) 3600W
• Potencia RMS a 4 ohmios 4 x 200 W
• Potencia RMS a 2 ohmios 4 x 320 W
• Potencia RMS a 4 ohmios Puente 2 x 600 W

Audio:

• Respuesta de frecuencia 20Hz-20KHz
• Relación señal-ruido >90 dB
• Eficiencia a 4 ohmios 88%
• Factor de amortiguación 160
• Impedancia de entrada 20K ohmios
• Separación de canales 60dB
• Distorsión Armónica Total (THD) 1.00%
• Rango de entrada de bajo nivel 0,2-6 V
• Entrada de alto nivel No
• X-Over seleccionable FULL/LPF/HPF
• Rango de filtro X-Over 40Hz-4KHz
• Rango de refuerzo de graves No
• Frecuencia de refuerzo de graves N/A
• Filtro infrasónico No
• Selector de fase No

Mediciones:

• Longitud total 10"/254 mm
• Ancho total 7,24"/184 mm
• Altura total 2"/53 mm
• Longitud del disipador de calor 8,54"/217 mm
• Peso bruto unitario individual 5 LB
