DS18 DSP8.8BT 8-Channel Digital Sound Processor with 8 Rca Inputs and Bluetooth Connectivity
DS18 proudly presents the DSP8.8BT: a 8-channel in and 8-channel out digital sound processor designed to revolutionize your car audio experience. At DS18, we understand that true audiophiles seek control – absolute dominion over every aspect of their sound-stage. The DSP8.8BT is your key to unlocking that control, putting the immense power of your audio system at your fingertips.
Highlights
Creating the perfect audio system has never been easier, thanks to the DSP8.8BT's intuitive features. Our BT Interface grants you direct access to an extensive list of filtration settings, ensuring that your sound is tailored precisely to your preferences. Our dedicated DSP8.8BT Application, available on both the App Store and Google Play, dares you to fine-tune and monitor every aspect of your signal processing. Effortlessly save presets for specific songs or genres, creating the ideal listening experience every time.
The DS18 DSP8.8BT takes audio tuning to an entirely new level with its 31 Band Graphic Equalizer. This advanced feature grants you the power to finely adjust the audio response across a wide range of frequencies. With this level of control, you can precisely target and eliminate peaks and dips in specific frequency ranges, ensuring that every note is reproduced with utmost accuracy. Fine-tune the tonal balance of your music, bringing out the best in each instrument and vocal, and achieving a sound signature that suits your personal preferences.
The DS18 DSP8.8BT goes a step further by offering adjustable crossovers on each channel, allowing you to fine-tune the separation between different audio components. With the ability to customize crossover points from 6 to 48dB/octave, you have unprecedented control over how frequencies are divided and sent to your speakers, amplifiers, and subwoofers.
Highlights
- Bluetooth connectivity to allow for easy and accessible audio tuning
- Easy to use software found on Google Play or the App Store to fine tune and monitor every aspect of your signal processing.
- 8 Channel RCA and/or HI-level speaker inputs
- 8 Channel RCA outputs
- Parametric equalizer with 8 independent band per channel
- Crossover with filters: Butterworth, Linkwitz-Riley and Bessel.
- Working Voltage 9 - 16 VDC
- Remote Input Voltage 9 - 16V
- Remote Output Voltage 12.8V (0.5A)
- Fuse Size 2 Amp
- THD + N< 1%
- Frequency Response 20Hz-20KHz (+/- 0.5dB)
- Signal to Noise Ratio @ A Weighted >100dB
- Input Sensitivity 0.2 - 9V
- Input Impedance 20k ohms
- Maximum Pre-Out Level (RMS)8V
- Pre-Out Impedance 200 ohm
- Crossover Frequency Variable HPF/LPF 20Hz to 20KHz
- Crossover Slope Select-able 6/12/18/24/36/48 dB/Oct
- Equalization 31 Bands Parametric
- Q Factor Select able 0.05 to 20
- EQ Presets Yes POP/Dance/Rock/Classic/Vocal/Bass
- User Presets Yes Basic / Advanced
- DSP Speed 147 MIPS
- DSP Precision 32-Bit
- DSP Accumulators 72-Bit
Digital to Analog Conversion (DAC):
- Precision 24-Bit
- Dynamic Range 108dB
- THD + N -98dB
Analog to Digital Conversion(ADC):
- Precision 24-Bit
- Dynamic Range105dB
- THD + N -98dB
- High / Low Level Input Up to 8 channel
- Low Level Output Up to 8 Channel
- Type RCA (Female)
- Length 6.37"/162 mm
- Depth 3.6"/91.5 mm
- Height 1.24"/31.7 mm
