• 3-Way Design implemented through use of two tweeters per speaker for full range quality on every listen
• Rubber surrounds with treated paper cones for great volume and sensitivity to power ratio

• Nominal Diameter: 6x9" / 152x228mm
• Nominal Impedance: 4 Ohms
• RMS Power Handling: 60W
• MAX Power Handling: 180W
• Sensitivity (1w/1m): 86dB
• Frequency Response: 35Hz-20KHz
• Recommended HI Pass Crossover: 50Hz

• Voice Coil Diameter: 1" / 25.5mm
• Voice Coil Former Material: ASV
• Winding Material: EISV
• Cone Material: Paper
• Surround Material: Rubber
• Basket Material: Steel
• Basket Color/Finish: Black Matte
• Magnet Material: Barium Ferrite
• Magnet Weight: 15.7Oz / 445g

• Nominal Diameter Tw1: 2.3" / 59mm - Tw2: 1.1" / 29mm
• Voice Coil Diameter Tw1: 0.6" / 17mm - Tw2: Peizo
• Voice Coil Former Material  Tw1: PESV
• Winding Material  Tw1: EISVM
• Diaphragm Material Tw1: Mylar - Tw2: Mylar
• Magnet Material Tw1: Barium Ferrite
• Magnet Weight Tw1: 34g

• Overall Diameter: 6.4"x9.2" / 163x234mm
• Overall Depth: 3.85" / 97.8mm
• Overall Diameter (With Grill): 7.24"x10.4" / 184x264mm
• Overall Depth (With Grill): 4.15" / 105.5mm
• Front Mount Baffle Cutout: 5.9x8.66" / 150x220mm
• Mounting Depth: 2.95" / 75mm
• Motor Diameter: 4.17" / 106mm
• Tweeter Protrusion: 0.9" / 22.8mm
